Khoom Description
Lub ntxaib sphere roj hmab expansion sib koom ua ke yog tsim los ntawm cov roj hmab sab hauv thiab sab nrauv, cov ntaub thaiv npog, thiab cov hlua hlau hlau, uas yog vulcanized thiab tom qab ntawd xoob ua ke nrog cov hlau flanges los yog cov pob qij txha. Lub pob ob lub pob tsim txhim kho huab cua nruj thiab kev ua haujlwm tsis muaj dej tsis zoo ntawm cov khoom, thaum ua kom nws lub neej ua haujlwm zoo thiab txo cov suab nrov. Nws qhov tshwj xeeb ob txheej txheej sealing ua tiav cov dej zoo nruj thiab huab cua nruj, ua rau nws muaj kev sib khi zoo heev.
|
TSIS MUAJ |
Lub npe |
Khoom siv |
|
1 |
Sab hauv / sab nraud roj hmab |
NR, NBR, EPDM, FKM, PTEF, IIR, CR |
|
2 |
Reinforced qaum |
Nylon Tyre Cord |
|
3 |
Lub nplhaib txhawb zog |
Stainless hlau muaj zog nplhaib |
|
4 |
Flange |
Q235, SS304, SS316, PVC |
Cov yam ntxwv ua haujlwm
1. Zoo siab tsis kam
2. Zoo heev corrosion kuj
3. Zoo buffering muaj peev xwm
4. Yooj yim rau nruab thiab tswj
Khoom Specification
|
Loj |
Ntev |
Tso cai txav hauv kev ua haujlwm |
||||
|
mm |
nti |
mm |
Axial Compression mm |
Axial Extension |
Transverse Movement mm |
Angular Deflection mm |
|
40 |
1 1/2 |
178 |
30 |
50 |
45 |
40 degree |
|
50 |
2 |
178 |
30 |
50 |
45 |
40 degree |
|
65 |
2 1/2 |
178 |
30 |
50 |
45 |
40 degree |
|
80 |
3 |
178 |
30 |
50 |
45 |
40 degree |
|
100 |
4 |
229 |
35 |
50 |
40 |
35 degree |
|
125 |
5 |
229 |
35 |
50 |
40 |
35 degree |
|
150 |
6 |
229 |
35 |
50 |
40 |
35 degree |
|
200 |
8 |
330 |
35 |
60 |
35 |
30 degree |
|
250 |
10 |
330 |
35 |
60 |
35 |
30 degree |
|
300 |
12 |
330 |
35 |
60 |
35 |
30 degree |
|
350 |
14 |
340 |
35 |
60 |
35 |
30 degree |
|
400 |
16 |
340 |
35 |
60 |
35 |
30 degree |
|
450 |
18 |
340 |
35 |
60 |
35 |
30 degree |
|
500 |
20 |
340 |
35 |
60 |
35 |
30 degree |
|
600 |
24 |
340 |
35 |
60 |
35 |
30 degree |
Lus Cim: Yog tias qhov nruab nrab yog cov roj, acidic lossis alkaline, thiab muaj cov kev cai tshwj xeeb rau kev ua haujlwm kub, koj tuaj yeem kho nws los ntawm kev xa ntawv lossis kos duab. Thov qhia thaum xaj.
Khoom Paub meej
Qhuav Flow
Cov khoom nyoos
Sab saum toj qib CR / EPDM / NBR
roj hmab raw cov ntaub ntawv, tsis siv roj hmab
Plasticating thiab sib tov
Tshwj xeeb formulation rau zoo dua dabtsi yog khoov nrog nylon, kom zoo zog, sealing
Workblanks qhwv
Cooper plated steel hlau reinforcement tiv thaiv rub tawm
Vulcanizing
Tsis siv neeg vulcanization tshuab xyuas vulcanization lub sij hawm thiab siab
Kev tshuaj xyuas
100% kev soj ntsuam nruj heev yog lub luag haujlwm rau cov neeg siv khoom
Ntim
Kev tiv thaiv ntim rau tsis muaj
xeb thiab tawg
Daim ntawv thov
Twin sphere roj hmab expansion pob qij txha muaj lub siab ua haujlwm zoo, hnav tsis kam, corrosion kuj, thiab seismic kev ua tau zoo, uas tuaj yeem nqus tau qhov kev vibration thiab txav chaw tsim los ntawm cov kav dej thaum ua haujlwm, tiv thaiv cov kav dej thiab khoom siv los ntawm kev puas tsuaj. Ob lub pob roj hmab pob qij txha tau dav siv hauv cov kav dej xws li petrochemicals, cua sov, cua txias, dej, thiab dej.
Peb Cov Kev Pabcuam
1.24- teev online
2.Cov qauv dawb muab
3.Txhawb customization
4. Muab cov duab kos
5.Ntau hom kev them nyiaj xaiv los ntawm
6.Kev tshuaj xyuas lub Hoobkas (khoom siv, specifications, kom muaj nuj nqis, siab, ntim)
7.Long warranty lub sij hawm
8.Suitable ntim rau kev thauj mus los
Peb Cov Neeg Siv Khoom
Daim ntawv pov thawj
FAQ
Q: Lub zog ua haujlwm yog dab tsi?
Q: Qhov kub ua haujlwm yog dab tsi?
Q: Puas tuaj yeem muab ob npaug rau sphere roj hmab expansion sib koom ua ke nrog lub logo customized?
Q: Koj puas tuaj yeem muab cov duab kos?
